PCB FABRICATION
From Design Files to Physical PCBs.
Delivering High-Quality, Cost-Effective, and Fully Compliant PCBs for Every Application.
Printed Circuit Boards are the backbone of modern electronics. A product’s efficiency and long life are determined by the reliability of its PCB. As a leading PCB manufacturer and supplier, we deliver high- performance circuit boards for diverse electronic industries around the world.
At TechiesDesigns, quality is our priority, ensuring every PCB leaving our facility performs reliably. Every board we fabricate is designed to meet stringent electrical, mechanical, and environmental standards, ensuring your products perform flawlessly.
Our PCB fabrication services cover single-layer to multi-layer boards, utilizing high-quality materials, advanced surface finishes, and industry-standard processes. With end-to-end quality control, including electrical testing, visual inspection, and traceability, we ensure each PCB meets your exact requirements, from rapid prototypes to high-volume production. We deliver consistent, reliable PCB solutions tailored to your application. By combining advanced technology, engineering expertise, and customer-focused processes, we enable seamless electronics production on time.
Why Choose TechiesDesigns For PCB Fabrication Service?
High-Quality PCB Fabrication Solutions with Reliable Lead Times - from Prototype to Mass Production.
Our PCB Fabrication Workflow
Our PCB Inspection Methods
➥ Visual Inspection
Manual or automated surface inspection to detect visible defects such as scratches, misalignment, or solder mask issues.
➥ Sample Lot Inspection
Random sampling of production batches to validate process consistency and quality.
➥ Tin Sample Inspection
Examination of solder pads to verify tin thickness, adhesion, and solderability.
➥ E-Test (Electrical Test)
Flying Probe for low–medium volumes and Bed-of-Nails for high volumes to verify continuity, shorts, and opens.
➥ Cross-Section Analysis
Sectioning and microscopic analysis to check layer alignment, via plating, and lamination integrity.
➥ Impedance Coupon Test
Measurement of dedicated test coupons to confirm controlled impedance for high-speed designs.
Our PCB fabrication infrastructure
Printed Circuit Board Manufacturing Process & Equipment
- Automated Optical Inspection [AOI]
- Pre-production Engineering Team
- Photo plotter - Photographic film processor
- Impedance Control Testing Machine
- PCB Board Cutting Machine
- Inner layer registration welding machine
- Multi-layer vacuum lamination (pressing)
- CNC drilling machines - 7 spindles
- CNC routing machines - 4 spindles
- Automatic PCB Grinding Brushing Machine
- Desmear Electroless Automated Line
- Dryfilm photo resist laminator
- Imaging- Laser Direct Image
- Electroplating copper and tin line
- Dryfilm photoresist stripping machine
- Etching and tin stripping machine
- Brown oxide line
- Mec etch surface cleaning line
- Vertical hot air leveling machine
- ENiG line
- Inkjet Legend Printing
- Fly probe tester - 3 nos
- Control impedance Speed Stack & Coupon Generator
- Control impedance testing equipment
- Waste water treatment plant (RO)
- Video measuring equipment
- CMI-hole wall copper thickness measuring equipment
- CMI-surface copper thickness equipment
PCB Etching Equipment | Wet Processing Equipment | Chemical Milling Machines
With specialized equipment and skilled engineers, we consistently deliver high-quality PCBs that earn our clients’ trust.
